Below is an overview of typical DJI GSPRO an DJI Pilot settings for plant phenotyping multi-spectral flights.
Plant Phenotyping MSP - DJI GSPRO
|
|||
|
Data Product |
Plant Phenotyping |
||
|
Flight Type |
MSP |
||
|
GSPro settings |
General |
Product Type |
3D Map Area |
|
Basic parameters |
Shooting angle |
Parallel to main path |
|
|
Capture mode |
Capture at Equal Time Interval |
||
|
Flight course mode |
Scan Mode |
||
|
Resolution |
1cm/px; 2 cm/px; 3cm/px or 5cm/px |
||
|
Advanced parameters |
Front overlap |
80 |
|
|
Side overlap |
80 |
||
|
Gimbal pitch |
-90 (nadir) |
||
|
Course Angle |
Use the Course Angle to align the flight path to fly along the longest axis of the field |
||
|
Margin |
Adjust such that the flight path Is at least 2 flight lines outside the boundaries in all directions |
||
|
|
|
Flight lines |
Area should be completely covered and extended with at least 2 flight lines at each side. This because we should at least have pictures of all GCPs from all directions! Along the longest axis of the field! |
|
|
|
Timing & cloud cover |
From 10am -4pm
|
|
|
|
Example |
|
Plant Phenotyping MSP - DJI Pilot |
|||
|
Data Product |
Plant Phenotyping |
||
|
Flight Type |
MSP |
||
|
DJI Pilot settings |
General |
Mission Type |
Mapping |
|
Basic parameters |
Smart Oblique |
OFF |
|
|
Altitude mode |
Relative to take-off point (ALT) |
||
|
Target Surface to Take-off |
Set elevation difference between take-off and elevation at ROI |
||
|
GSD |
1cm/px; 2 cm/px; 3cm/px or 5cm/px |
||
|
Take-off Speed |
Default |
||
|
Advanced parameters |
Front overlap |
80 |
|
|
Side overlap |
80 |
||
|
Course Angle |
Use the Course Angle to align the flight path as such to fly along the longest axis of the field |
||
|
Margin |
Adjust such that the flight path Is at least 2 flight lines outside the boundaries in all directions |
||
|
Photo Mode |
Trigger on Distance |
||
|
Focus Mode |
First Waypoint Autofocus |
||
|
Dewarping |
OFF |
||
|
|
|
Flight lines |
Area should be completely covered and extended with at least 2 flight lines at each side. This because we should at least have pictures of all GCPs from all directions! Along the longest axis of the field! |
|
|
|
Timing & cloud cover |
From 10am - 4pm No cloud cover restrictions |
|
|
|
Example |
Check predicted weather conditions. The above weather and timing limitations should be taken into account depending on the product type. |
